Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: 3rd Eye
  • Model Number: TE810H
  • Small size DVR: 131mm x 86mm x 18mm
  • Super light DVR: 205g
  • Mini Size Camera: 1.95X8cm,30g
  • long recording time: Up to 9.5 hours
  • High Resolution: 720X586pix(PAL),720x480pix(NTSC),480TVL
  • Photo function: take, review & store pictures
  • motion detect video recording: Support
  • loop recording: Support
  • mounting brackets: Supports multi-language
  • 6 bright LED or IR light: 5/8 meters clear view in complete darkness

Packaging & Delivery

Packaging Details netrual packing; G.W.:1.0kgs

2.4G Headware Wireless Camera System (Night Vision camera+5 inch DVR)

5 Inch LCD HD Wireless Mini DVR+6 LED/IR Night Vision Gutter Inspection Camera(6 LED or IR for 5/8M night view,loop recording,large memory)

Model:TE810H



The included portable wireless inspection camera is our company developed simple and convenient inspection instrument.It can be used to inspect hard-to-reach, darkness, dangerous places, such as:Auto engine and gearing inspection; Medical inspection, like dental, skin disease, gynecology, etc.; All kinds of pipe & tube, building inspection; Antiterrorism search & rescue; Safety inspection; Archeology, etc.

 Users can view the instant inspection detail on this 5 inch HD screen. They also can record videos and take pictures. Look over some recorded video repeatedly to find out the source problem. If the video is not satisfactory, users can delete it and rerecord. DVR memory is large up to 32GB. Li-battery time is long to 9.5 hours.


Selling points:
*Super small size  & light weight camera & DVR, very convenient to carry;
*High resolution 720X576pix(PAL),720x480pix(NTSC),520TVL camera offers good quality video;
*6 LED/IR lamps offers 5 or 8 meters clear view in complete darkness;(LED can be highlight or turned off;IR is invisble light);
*High capacity built-in Li-battery offers power supply for camera and DVR anywhere;
*No need any installation, and very easy to operate, just power on and it works!
* First complete wireless mini inspection camera with LED in the world!
* Portable 5-inch HD(800X480pix) DVR offers both real time and recorded videos & photos;
* Motion detect recording and loop recording available;
* Large memory available( support mini SD card up to 32GB)
* Wireless transmission offers convenience for remote view.



Specification:




Specifications:



Items
Value
Wireless Receiving

( Choose 1 group of frequency from 2.4G/within 5.8G/beyond 5.8G)
2.4GHz –8 channels
CH1: 2414MHz; CH2: 2432MHz; CH3: 2450MHz; CH4: 2468MHz.
CH5: 2490MHz; CH6: 2510MHz; CH7: 2390MHz; CH8: 2370MHz
Within 5.8G—8 channels
CH1: 5865MHz; CH2: 5845MHz; CH3: 5825MHz; CH4: 5805MHz.
CH5: 5785MHz; CH6: 5765MHz; CH7: 5745MHz; CH8: 5725MHz
Beyond 5.8G—8 channels
CH1: 5705MHz; CH2: 5685MHz; CH3: 5665MHz; CH4: 5645MHz.
CH5: 5885MHz; CH6: 5905MHz; CH7: 5925MHz; CH8: 5945MHz
Sensitivity
-92dB
Receiving distance
100 meters
AV IN
TV system
NTSC / PAL
Output voltage
3.6-4.2 V
HD 5-inch LCD screen
Active area
108mm(W) X 64.8mm(H)
Resolution
800 X 480 Pixel
Luminance for LCM
200 cd/m²
Cape clear 5-inch LCD screen
Active area
118mm(W) X 62.8mm(H)
Resolution
480 X 272 Pixel
Luminance for LCM)
300cd/m²
Video
Resolution
720*576 / 640*480
Video compress
MPEG-AVI    30fps
Play format
MPEG-AVI
Audio
Frequency
20HZ-20KHz stereo
Earphone Output
Left: 20MW+ right 20mW [16O](suit to largest volume)
Speaker
1W
Format
JPG/JPEG
Storage
External SD card
TF card 1GB-32GB(optional)
32GB recording time
10-32 hours
1GB photos
15625pcs
Operating system
PC
Windows & Mac OS
Port
USB 2.0
Language
Multiple
Power
Voltage
DC 5V
Current(receiving mode)
660MA
Current( recording mode)
680MA
Current(recording with off-screen mode)
340MA
AC adapter
DC 5V 2A
Built-in battery
Li-battery 3200mAh
Standby time
Wireless record
≥9.5 hours(off-screen); ≥5hours(on-screen)
Wired record
≥12 hous(off-screen); ≥6hours(on-screen) *LED camera not included.
Size (L x W x H)
131mm x 86mm x 18mm
Weight(g)
205g








Company Information









Our Services

OEM&ODM available



Silk print logo on the product or on the start page of the DVR.

Customized Color box or user manual.

Any of your idea on our product we can help you to design and put it into production.

High quality, fashion designs, reasonable&competitive price fast lead time.





After-Sale service



All products will have been strictly Quality checked in house before packing.

All products will be well packed before shipping .

All of our products have 1 year warranty.

And we sure the product will be free from maintenance within warranty period.





Fast delivery



Sample orders in stock, and 3-5 days for bulk production
